ECO STAR PLUS-B PATHOLOGICAL BINOCULAR MICROSCOPE
| Magnification |
40x
|
| Illumination |
LED
|
| Is It Portable |
Non Portable
|
| I Deal In |
New Only
|
| WARRANTY |
1 YEAR
|
| BRANDS |
QUASMO
|
| Country of Origin |
Made in India
|
| Minimum Order Quantity |
1 Piece
|
Description
ECO STAR PLUS-B PATHOLOGICAL BINOCULAR MICROSCOPE
- Optical System: Finite Optical System
- Stand: Aluminium Die-cast Stand (Anti-Rust) Body.
- Viewing Head: Binocular Head 30° Inclined 360° Rotatable, IPD 48-75mm With Diopter Adjustment.
- Eye Guards: Adjustable Rubber Eye Guards For Comfortable Viewing.
- Eyepieces: Wide Field 10x, F.O.V 18mm (Optional 10x/20mm), Antifungal & Anti-reflection Coated.
- Nosepiece: Forward Quadruple Revolving Nosepiece With Click Stops Mechanism and Rubber Grip.
- Magnification: 40x To 1000x.
- Objectives: Semi Plan Achromatic 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 Oil (SL).
- Mechanical Stage: Double Plate Graduated Stage Size 135mm x 150mm, X/Y Travel Range 80mm X 55mm. Double Specimen Holder Clip.
- Focusing Control: Co-axial Coarse And Fine Focusing With 0.2mm/rotation.
- Condenser: Movable Abbe Condenser, N.A. 1.25 Anti Fungal, Anti Reflection With Aspheric Lens, Iris Diaphragm With Frosted White/Blue.
- Illumination: Halogen 6V-20W (Upto 20,000 hours) or 3W LED Light (Up To 100,000 Working hours) with Intensity Controller.
- Power: Universal Power Supply 110v-240v Integrated With Voltage Flux Stabilizer.
- Packaging: Inner Thermocol/Styrofoam Packing And Outer Cardboard Box.
