QHD 2D/3D 360˚


Ratio: 1:8.3

Optical Magnification: 0.6-5.0 X

Working distance: 86mm

2D/ 3D view: 360˚ rotation, 45˚ objective viewing angle




Optical Magnification 0.6-5.0 X
Total Magnification 11-95 X base of 12.5 inches monitor
Working distance 86mm
Ratio 1:8.3
Field of View 24*13.5 – 2.88 * 1.62mm
Lens Mount Standard C Mount

2D/ 3D view

2D and 3D manual free switch
Working Distance always remains same
The Center position Remains same
360˚ rotation, 45˚ objective viewing angle
Image Sensor 1-2 inches SONY CMOS
Max Magnification 1920X1080
Pixel Size 3.75mm X 3.75mm
White Balance Manual and Auto
Brightness Control Manual and Auto
Record Format Snapshot, Picture format; JPG


Image Output Interface HDMI
Size 12.5 inches
Resolution 1920*1080
Color Display 16.7M
Brightness 300NIT
Contrast 800:1
Visible Angle 170˚ Horizontal and Vertical
Power Supply Adaptor: Input: AC100240V/50  ̴ 60Hz;

Output: DC  12V/5A/60W;

Monitor: USB-A-Output DC5V/2AX3

Image input interface HDMI1, HDMI2
Light Control 4 zones control, Brightness Adjust
Light Color White
Quantity of LED 208 PCS of LED
 Intensity 15000 LUX
Wavelength 455-457.5nm
Output Voltage 12V
Output Power 8-10W
Working Distance 35-110 mm
Material Aluminum Alloy
Diameter Inner Diameter: 40mm, Height: 19mm,

Outer Diameter: 106mm

Base Size 330*300mm
Height 328mm
Scope Holder 50mm
