QX-40 RESEARCH TRINOCULAR MICROSCOPE
| Magnification |
1000x
|
| Is It Portable |
Non Portable
|
| Brands |
QUASMO
|
| WARRANTY |
1 YEARS
|
| Mechanical Stage |
190mm X 170mm
|
| Illumination |
5W LED Light
|
| Power |
110v-240v
|
| Country of Origin |
Made in India
|
| Minimum Order Quantity |
1 Piece
|
Description
QX-40 RESEARCH TRINOCULAR MICROSCOPE
- Optical System: Infinity Optical System.
- Stand: Single Mould Sturdy Y-Shaped Aluminum Die-cast Stand (Anti- Rust) Body.
- Viewing Head: Siedentopf Trinocular Head 30° Inclined 360° Rotatable, IPD 48-75mm With Diopter Adjustment.
- Eye Guards: Adjustable Rubber Eye Guards For Comfortable Viewing.
- Eyepieces: Wide Field 10x, F.O.V 22mm With +/-5 Diopteric Adjustment, Antifungal & Anti-reflection Coated.
- Nosepiece: Inward Quintuple Revolving Nosepiece With Click Stops Mechanism and Rubber Grip.
- Objectives: Infinity Plan Achromatic 4x/0.10, 10x/0.25, 20x/0.40, 40x/0.65 (SL), 100x/1.25 Oil (SL).
- Magnification: 40x To 1000x.
- Mechanical Stage: Double Plate Graduated Stage Size 190mm X 170mm, X/Y Travel 80mm X 50mm, Rack Less, Scratch-resistant, Double Specimen Holder Clips.
- Focusing: Coaxial Coarse And Fine Focusing. With Fine Adjustment Scale Value 0.002mm.
- Condenser: Movable Abbe Condenser, N.A. 1.25 Anti Fungal, Anti Reflection With Aspheric Lens, Iris Diaphragm With Frosted White/Blue.
- Illumination: 5W LED Light, Dc 12V 2A (Up To 100,000 Working hours) with Intensity Controller.
- Power: Universal Power Supply 110v-240v Integrated With Voltage Flux Stabilizer.
- Packaging: Inner Thermocol/Styrofoam Packing And Outer Cardboard Box.
